ROCSECURE EX32
ADVANCED ENCRYPTION, MOST SECURE & FASTEST PORTABLE STORAGE SOLUTION
The new Rocsecure EX32 utilizes the new USB 3.1 technology for the fastest throughput & transfer rate. The EX32 uses the most advanced AES 256-bit real-time hardware encryption. The cryptographic encryption processor is FIPS 140 Level-2 and NIST SP800-171 certified. It also meets the strictest Cybersecurity Maturity Model Certification (CMMC) Compliance The Rocsecure EX32 has the latest innovative encryption technology with more power and speed. Our cryptographic processor performs full disk encryption protecting entire Data-at-Rest. The Full Disk Encryption (FDE) solution is OS independent with no extra software, or driver component needed. The EX32 uses a single secure token key authentication methods for unprecedented user access to the drive and data.
Technology
Unparalleled encryption Technology.
Real-time hardware security at its core.
The Rocstor EX32 encryption technology is engineered to encrypt/decrypt the entire SATA hard disk or SSD drive including the boot sector, temporary files, and operating system with SATA Gen 3 speed at 6Gbps. Rocstor’s latest technology is not comparable to any other device available in the market. Our technology has the most enhanced security, performance, and speed with FIPS 140-2 level 2 cryptographic processor certification. The EX32 encryption engine is NIST certified, and it requires secure token key for authentication method.
USB 3.1 connectivity. Up to 450Mbps transfer speed.
Fast and powerful encryption like no other drive.
The Rocsecure EX32 takes advantage of USB 3.1 Gen1 throughput speeds. Connect the EX32 encrypted drive to a USB 3.1 (or higher) port of a host computer and then take advantage of encrypted data transfer speeds of up to 450 Mbps. Making this drive one of the fasted, most secure encrypted drives available in the market.
Rocsecure EX32 is built on the latest FIPS Encryption engine and USB 3.1 Gen1 technology. When using Solid State Drives models connected to your host computer’s USB-C port, you will experience up to 450 Mbps transfer speeds and performance which is unmatched to any other real-time encrypted drives in the market. Rocsecure EX32 includes solid-state drives that are blazing fast, with up to a 7.68TB capacity.
Powerful
Advanced security.
One of the most secure and cutting-edge hardware-based encryption chipsets is integrated into the internal circuitry of Rocsecure EX32 models. The chipset contains features such as Advanced Encryption Standard Algorithm AES-256 bit key strength, and real-time encryption so that there is virtually zero time in encrypting and decrypting the data. The encryption engine bears certifications from the National Institute of Standards and Technology SP800-171 (NIST), and FIPS Level 2 for a Cryptographic Module.
Validated.
EX32 Authentication Operation
The Rocstor Rocsecure EX32 CryptoKey™ tokens are the safest and most secure way of authentication method. A Rocstor Secure CryptoKey™ Token Key is required to be inserted for authentication before the host computer can mount the drive. Once EX32 is connected and the authentication is validated, the token key must be removed before the EX32 HDD/SSD volume is mounted or displayed.
Design
Aluminum ruggedized frame, shock absorbent
The Ruggedized Portable Enclosure aluminum design helps to protect your hard drive and data. The safety-centric mechanical design of Rocsecure EX32 series 2.5″ enclosures provide critical hardware protection features, including:
The Rocsecure EX32 is made with aircraft-grade aluminum, making this enclosure both ruggedized and durable. An exclusive shock-absorbing mechanism is built into the enclosure. Its function is to keep the hard drive suspended within the casing while dissipating the heat produced by the hard drive. The EX32 is designed this way to allow peak performance while operating at an optimal temperature. The bus-power feature off¬ers the user added convenience by eliminating the need to carry nonstandard and sometimes hefty adaptors and cables that are normally required to power typical hard drives.
• Secure Shock-Absorbent Mechanism
The full-length bridgeboard provides additional protection by supporting the entire length of the hard drive. A strong aluminum rim holds the hard drive chassis firmly in place, eliminating stress on the bridgeboard and preventing damage due to impact or violent movement.
• Shock-Absorbent Protection
The shock-absorbent dampers strip between the bridgeboard and chassis offers additional resistance against accidental drops and bumps. The disposition of the hard drive and housing profile form an anti-shock chamber to cushion the blow of potential impacts.
• Thermal Protection and Load-Bearing Case
The precision density of the rugged aluminum aircraft-grade border provides excellent heat dissipation and is strong enough to bear external weight.
Protection
Mil-Standard waterproof case
Rocstor HXA Injection Molded Mil-Standard Waterproof Cases are molded of ultra-high-strength polypropylene copolymer resin, featuring a gasketed, water and dust tight, submersible design (MIL-C-4150J) that is resistant to corrosion and impact damage. Features a molded-in hinge, patented trigger release latch system, comfortable, snap-down rubber over-molded cushion grip handle, automatic ambient pressure equalization valve (MIL-STD-648C), resistance to UV, solvents, corrosion, fungus and impact damage (MIL-STD-810F).
Warranty |
|
| Limited Warranty | 2 Year |
Interfaces/Ports |
|
| Host Interface | USB 3.1 |
| Drive Interface | SATA |
Technical Information |
|
| Storage Capacity | 500GB | 1TB | 2TB HDD - 500GB-SSD | 1TB-SSD | 2TB-SSD | 4TB-SSD | 7.68TB-SSD |
| Encryption Standard | 256-bit |
General Information |
|
| Product Type | Hard Drive |
| Manufacturer | Rocstor |
| Product Model | EX31 |
| Product Name | Rocsecure EX32 Real-time Hardware Encrypted Portable External Hard Drive |
| Product Line | Rocsecure |
Miscellaneous |
|
| Brand Name | Rocstor |
| Package Contents | Rocsecure EX32 Real-time Hardware Encrypted Portable External Hard Drive "USB-C to USB-C Cable, USB-C TO USB 3.0 Type A Cable, (3) Secure Token Key" Carrying Case |
Physical Characteristics |
|
| Weight (Approximate) | 8 oz |
| Color | Silver |
| Drive Type | External |
| Form Factor | 2.5" |
| Height | 0.7" |
| Width | 2.9" |
| Depth | 5" |
| External Drive Type | Portable |
Rocstor PN |
Description |
| E680XX-01 | Rocsecure EX32 - USB 3.0/USB 3.1 - Encrypted Portable Drive Enclosure Only- Encrypted AES-256 - FIPS 140-2 Compliant - Includes (3) HMAC Token Keys - TAA Compliant |
| E68010-01 | Rocsecure EX32 - 500GB - 5400 rpm - USB 3.1(USB 3.0) – Portable – Encrypted AES-256 – CMMC & NIST SP800-171 Compliant, FIPS 140-2 Inside Validated – Portable Drive with (3) Token Keys – TAA Compliant |
| E68012-01 | Rocsecure EX32 - 1TB - 5400 rpm - USB 3.1(USB 3.0) – Portable – Encrypted AES-256 – CMMC & NIST SP800-171 Compliant, FIPS 140-2 Inside Validated – Portable Drive with (3) Token Keys – TAA Compliant |
| E68014-01 | Rocsecure EX32 - 1TB - 7200 rpm - USB 3.1(USB 3.0) – Portable – Encrypted AES-256 – CMMC & NIST SP800-171 Compliant, FIPS 140-2 Inside Validated – Portable Drive with (3) Token Keys – TAA Compliant |
| E68016-01 | Rocsecure EX32 - 2TB - 5400 rpm - USB 3.1(USB 3.0) – Portable – Encrypted AES-256 – CMMC & NIST SP800-171 Compliant, FIPS 140-2 Inside Validated – Portable Drive with (3) Token Keys – TAA Compliant |
| E68018-01 | Rocsecure EX32 - 500GB SSD - USB 3.1(USB 3.0) – Portable – Encrypted AES-256 – CMMC & NIST SP800-171 Compliant, FIPS 140-2 Inside Validated – Portable Drive with (3) Token Keys – TAA Compliant |
| E68020-01 | Rocsecure EX32 - 1TB SSD - USB 3.1(USB 3.0) – Portable – Encrypted AES-256 – CMMC & NIST SP800-171 Compliant, FIPS 140-2 Inside Validated – Portable Drive with (3) Token Keys – TAA Compliant |
| E68022-01 | Rocsecure EX32 - 2TB SSD - USB 3.1(USB 3.0) – Portable – Encrypted AES-256 – CMMC & NIST SP800-171 Compliant, FIPS 140-2 Inside Validated – Portable Drive with (3) Token Keys – TAA Compliant |
| E68024-01 | Rocsecure EX32 - 4TB SSD - USB 3.1(USB 3.0) – Portable – Encrypted AES-256 – CMMC & NIST SP800-171 Compliant, FIPS 140-2 Inside Validated – Portable Drive with (3) Token Keys – TAA Compliant |
