JetConnect JC016 16-Port Gigabit Desktop / Rack mount Unmanaged Network Switch


JetConnect JC16 16-Port Gigabit Desktop / Rackmount Unmanaged Ethernet Switch, 16x 10/100/1000 Adaptive RJ-45 Ports, 2 Layer Supported, Metal, Conforms to IEEE 802.3 / 802.3u / 802.3ab Standards – UL Certified – Rack mount – TAA Compliant – Black

SKU: Y10S003-B1 Categories: , , Tag:


The Rocstor JetConnect JC16 Ethernet Switch is a versatile networking solution designed to cater to various applications such as small home offices, internet cafes, schools, and small/medium enterprises. With its full Gigabit capability, this switch is designed to upgrade networks to Gigabit speed, meeting high bandwidth requirements for seamless data transmission. Featuring 16 10/100/1000Mbps Adaptive Ethernet Ports, each supporting full line speed, non-blocking switching, and port auto flip functionality, the JC16 ensures efficient and reliable network performance.

The JC16 Ethernet Switch is Layer 2 supported, providing enhanced network capabilities. It conforms to IEEE802.3, IEEE 802.3u, and IEEE 802.3ab standards, ensuring broad compatibility with a wide range of devices. With 16 10/100/1000 Base-T ports, it offers ample connectivity options for multiple devices. The switch’s high back-plane bandwidth of 32 Gbps ensures efficient data handling and smooth communication across the network. Additionally, it features IEEE802.3x Flow control for optimized data flow and network stability.

One of the unique features of the JetConnect JC16 is its one-key function conversion, supporting three modes: normal mode, VLAN mode, and extend 250m mode. In normal mode, the switch operates with default settings. In VLAN mode, Ports 1-14 are isolated from each other and only communicate with the uplink ports 15-16. This feature enhances network security by controlling network storms and protecting information integrity. In extend 250m mode, Ports 1-14 can transmit data up to 492 ft (250 meters) using Cat5e/6 or higher network cables, while ports 15-16 operate normally.

The JetConnect JC16 is TAA compliant, meeting the requirements for government procurement. With its seamless, high-speed network experience, the JC16 ensures reliable connectivity and efficient data transmission. Backed by a 5-year warranty and lifetime technical support, Rocstor provides peace of mind and assistance throughout the product’s lifespan. Choose the Rocstor JetConnect JC16 Ethernet Switch for a robust and dependable networking solution.


• Conforms to IEEE802.3, IEEE 802.3u, IEEE 802.3ab
• Provides 16 10/100/1000 Base-T ports
• High back-plane bandwidth 32 Gbps
• IEEE802.3x Flow control
• The switch supports one-key function conversion, currently supports
three modes, normal mode,VLAN mode, extend 250m mode,

Normal: Normal mode, no special function
VLAN :1-14 port will not communicate with each other only communicate with uplink port 15-16. It will control the Net storm, protect the information security.
Extend 250m: 1 -14 port can transmit 250 meters, when using CatSe/6 network cable or better

Additional information

Weight 2.26 lbs
Dimensions 7.9 × 7.9 × 3 in

User Manual

Y10S003-B1 – User Manual


General Information
Product Type Ethernet Switch
Manufacturer Part Number Y10S003-B1
Manufacturer Website Address
Manufacturer Rocstor, Inc.
Product Model JetConnect JC16
Product Name JetConnect JC16 Unmanaged 16-Port Gigabit Switch
Brand Name Rocstor
Physical Characteristics
Weight (Approximate) 1.51 lb
Form Factor Desktop
Height 1.73″
Width 4.65”
Length 7.87”
Compatible Rack Unit 1U
Token Ring Port No
LRE Port No
Number of Network (RJ-45) Ports 16
Management Port No
Stack Port No
Total Number of Network Ports 16
Port/Expansion Slot Details 16 x Gigabit Ethernet Network




Management & Protocols
Manageable No
Network & Communication
Layer Supported                            2

Transmission Distance               Port 1-14 820 ft. (250 meters) with 1 O Mbps,

Port 15-16 328 ft. (100 meters) with

10/100/1000 Mbps

Media & Performance
Network Technology 10/100/1000Base-T
Ethernet Technology Gigabit Ethernet
Media Type Supported Twisted Pair
Certifications & Standards








  • IEEE 802.3: Ethernet
  • IEEE 802.3u: Fast Ethernet
  • IEEE 802.3x: Flow Control
  • IEEE 802.3ab: Gigabit Ethernet
  • Emissions: CE Mark A, FCC Class A
  • UL Certificate
Compliance TAA
Country of Origin Tia
Environmentally Friendly Yes
Power Description
Power Source Built-in Power Supply UL Certified
Voltage Range AC100 – 240V
Power Consumption <15 W
PoE (RJ-45) Port No
