USB Type-C 6-in-1 4K Multiport Adapter with DP 1.4 Alt Mode – USB C to HDMI 4K@60Hz, Gigabit RJ45 Ethernet, USB 3.0 Type-A, SD/Micro, USB-C 100W PD
$34.95
USB Type-C 6-in-1 4K Multiport Adapter with DP 1.4 Alt Mode – USB C to 1x HDMI 4K@60Hz, 1x Gigabit RJ45 Ethernet, 2x USB 3.0 Type-A, SD/Micro, 1x USB-C 100W PD – Black
The Rocstor Premium USB Type-C 6-in-1 4K Multiport Adapter is designed to enhance the connectivity options of Type-C and Thunderbolt 3/4 hosts, including PCs, laptops, and mobile phones. This versatile hub features an HDMI port, two USB-A ports, SD and Micro SD card slots, and a Type-C female port. It is perfect for devices with only one Type-C port, offering a comprehensive solution for various connectivity needs. Equipped with the latest DisplayPort 1.4 Alt mode supported IC, the adapter supports HDMI video output at a maximum resolution of 4K/60Hz while simultaneously enabling USB 3.0 data transfer at speeds up to 5Gbps.
The Rocstor 6-in-1 Adapter not only supports dual USB-A ports for connecting multiple devices but also includes SD/Micro SD slots that allow for the simultaneous use of two cards for efficient data transfer and information exchange. Additionally, the Type-C female port supports PD 3.0 charging with a maximum power delivery of 100W, ensuring your devices remain charged and ready for use. Compatible with all DP Alt mode supported Type-C hosts, this hub guarantees versatile compatibility and enhanced functionality.
Designed for robust performance and convenience, the Rocstor 6-in-1 Multiport Adapter supports HDR, HDCP 2.2 & 2.3, and HDCP 1.4, along with various color depth outputs, ensuring an exceptional visual experience. Whether you are using Windows or MacOS, this adapter is an essential accessory for maximizing your device’s connectivity and productivity. Backed by Rocstor 3-year limited warranty and lifetime free technical support.
Key Features:
- Multiport Expansion: Connects a single Type-C port to HDMI, two USB-A ports, SD/Micro SD card slots, and a Type-C PD charging port.
- High-Resolution HDMI Output: Supports 4K/60Hz resolution with DP 1.4 Alt mode.
- Dual USB-A Ports: Provide up to 5Gbps data transfer per port, with one port supporting max 7.5W (5V/1.5A) and the other supporting max 900mA downstream charging.
- Type-C PD Charging Port: Supports up to 100W PD charging with PD 3.0 Fast Role Swap, ensuring the connected device does not disconnect when plugging in or out the PD adapter.
- SD/Micro SD Card Slots: Allow simultaneous use of both cards, supporting Secure Digital v3.0 UHS-I for high-speed data transfer.
- HDR and HDCP Support: Ensures optimal video quality with enhanced depth, detail, brightness, contrast, and color gamut.
- Multiple Color Depth Outputs: Supports 6/8/10/12 bit color depth and various pixel formats (RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0).
- Wide Compatibility: Works with all DP Alt mode supported Type-C hosts, including Thunderbolt 3 and 4 ports.
- Enhanced Protection: Includes short-circuit, over-current, and over-voltage protection for safe and reliable performance.
- Warranty: Rocstor 3-Year Limited Warranty
Technology |
HDMI ,RJ45 ,SD/Micro card Reader ,USB-A ,USB-C |
---|---|
Host Connector |
USB-C |
Video Ports |
HDMI |
Number of Monitors |
1 |
Data Ports |
USB-A ,USB-C |
Network Ports |
RJ45 |
Special Features |
DisplayPort Alt Mode |
User Manual
Specification
[table type=”table-hover”]
Power Description
|
|
Maximum Power Supply Wattage | 100 W |
Warranty | |
Limited Warranty | 3 Year |
Miscellaneous | |
Package Contents | Main Unit x1 User Manual x1 |
Compatibility |
Surface Pro 7, Surface Pro 8, iPad Pro, HP Elite, MacBook, Dell,
|
Country of Origin | Vietnam |
Environmentally Friendly | Yes |
Physical Characteristics
|
|
Weight (Approximate) | 3oz (85g) |
Form Factor | Portable |
Height | 0.43in (1.1cm) |
Width |
4.53cm (device) 12.6in (with cable)
|
Length | 1.3in |
Product Color | Black |
General Information
|
|
Product Type | Docking Station |
Manufacturer Part Number | Y10A309-B1 |
Manufacturer Website Address | |
Manufacturer | Rocstor |
Product Name |
Rocstor Premium USB Type-C 6-in-1 4K Multiport Adapter USB C to 1x HDMI 4K@60Hz, 2x USB 3.0 Type-A (7.5W Charging), 1x SD/Micro Simultaneous, 1x USB-C 100W PD Charging
|
Brand Name | Rocstor |
Technical Information
|
|
Device Supported |
Notebook/Tablet PC
|
Connectivity Technology | Wired |
Memory Card Supported | SD 3.0 |
MicroSD 3.0 | |
Screen Mode Supported | Max 4K/60Hz |
Interfaces/Ports | |
Host Interface | USB-C Male x1 |
Video |
HDMI (DP Alt Mode) x1
|
Data | USB-A x2 |
PD Charging |
Type-C Female x1
|
Card Slot |
SD/Micro SD 3.0 x1
|
Software | |
Operating System Supported |
Windows 8, 10, 11
|
Android, ChromeOS, iPadOS
|
|
Mac OS 14, Mac OS X 13.0 Ventura, Mac OS X 12.0 Monterey, Mac OS X 11.0 Big Sur, Mac OS X 10.15 Catalina, Mac OS X 10.14 Mojave, Mac OS X 10.13 High Sierra
|
[/table]
Warranty
Limited Warranty: 3-Year
