Rocstor’s Active DisplayPort® to DVI 4K converts a DisplayPort computer output to single link DVI. For a clear and high-resolution quality images use this premium adapter which supports uncompressed High-Definition digital video up to 4K and up to 3840×2160 resolution at 30Hz. Additionally, it boasts a flexible design with good bending radius to ease cable management.
This adapter solution is for demanding users that require 4K high resolution for their computing and display needs. The DisplayPort® to DVI adapter provides an active conversion that can be used with any DisplayPort output with multi-mode DP++ signals. Rocstor provides a 3-year warranty and free lifetime technical support.
Rocstor Premium Active DisplayPort to DVI Adapter – 4K@30Hz
| Weight | 0.13 lbs |
|---|---|
| Dimensions | 9.45 × 7.01 × 0.62 in |
| Technology |
DisplayPort ,DVI |
| Connector 1 |
DisplayPort |
| Connector 2 |
DVI |
| Color |
| Rocstor Part# | Ingram Micro | TD Synnex US | TD Synnex CA | AB | B&H |
| Y10A230-B1 | 7QK436 | 5850395.0 | 7955971.0 | ROC-Y10A230-B1 | ROY10A230B1 |
General Information
| Manufacturer | Rocstor |
| Manufacturer Part Number | Y10A230-B1 |
| Manufacturer Website Address | http://www.rocstor.com |
| Brand Name | Rocstor |
| Product Name | DisplayPort to DVI Active Adapter |
| Marketing Information | Rocstor's Active DisplayPort® to DVI 4K converts a DisplayPort computer output to single link DVI. For a clear and high-resolution quality images use this premium adapter which supports uncompressed High-Definition digital video up to 4K and up to 3840x2160 resolution at 30Hz. Additionally, it boasts a flexible design with good bending radius to ease cable management.
This adapter solution is for demanding users that require 4K high resolution for their computing and display needs. The DisplayPort® to DVI adapter provides an active conversion that can be used with any DisplayPort output with multi-mode DP++ signals. Rocstor provides a 3-year warranty and free lifetime technical support. |
| Product Type | Video Cable |
Technical Information
| Cable Type | DisplayPort/DVI |
| Cable Length | 8' |
| Connector Type on First End | DisplayPort Digital Audio/Video - Male |
| Connector on First End Details | 1 x 20-pin DisplayPort Digital Audio/Video - Male |
| Connector Type on Second End | DVI-D Digital Video - Female |
| Connector on Second End Details | 1 x 25-pin DVI-D Digital Video - Female |
| Conductor | Copper |
| Device Supported |
|
| Supported Resolution | 3840 x 2160 |
| Features | Active |
Physical Characteristics
| Product Color | Black |
| Product Material | Copper |
| Material Details | Copper - Conductor |
| Weight (Approximate) | 0.12 lb |
Miscellaneous
| Environmentally Friendly | Yes |
| Country of Origin | China |
Warranty
| Limited Warranty | 3 Year |
